02-4058075079335
31. October 2024
02-4058075079397
31. October 2024
02-4058075079359
For further information, please refer to the data sheet!Minimum order quantity
6 pieces
Order step
6 pieces
Weight
0,527 kg
Product group
Downlight/spotlight/floodlight (EC001744)
Suitable for wall mounting
Yes
Dimming DALI-2
No
Constant luminous flux control
No
Adjustable beam angle
No
Max. Number of lights Circuit breaker C16
56
IFTTT support available
No
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
Suitable for truss mounting
No
Suitable for platform/floor mounting
No
Suitable for busbar mounting
No
Suitable for clamp mounting
No
Suitable for cable system
No
Light source
LED not replaceable
Suitable for number of light sources
0
Version
Without
Surface protection
powder-coated
Housing color
white
Brushed surface
No
Voltage type
AC
Nominal voltage
220 – 240 V
LED rated current with constant current
108 mA
Operating device
LED control gear, current-controlled
Without dimming function
Yes
Reflector
Without
Light distributor
Diffuser lens/optics/panel
Light distribution
symmetrical
Light emission
direct
Rated service life L70/B50 at 25 °C
30.000 h
Rated service life L80/B10 at 25 °C
20.000 h
Protection class (IP)
IP20
Impact resistance
IK03
Protection class
II
Rated ambient temperature according to IEC 62722-2-1
-20 – 50 °C
Max. System performance
18,00 W
Color temperature
4.000,00 K
Luminous flux
1.530,00 lm
Rated luminous flux according to IEC 62722-2-1
1.530 lm
Power factor
0,50
Width
225,00 mm
Height/depth
50,00 mm
Length
225 mm
Installation width
210 mm
Installation height/depth
50 mm
Installation length
210 mm
Type of wiring
Conclusion
Number of poles
2
Connection type
Plug-in terminal
Luminaire luminous efficacy
85 lm/W
Photobiological safety according to EN 62471
RG0
Suitable for surface mounting
Yes
Suitable for recessed mounting
Yes
Suitable for ceiling mounting
Yes
With illuminant
Yes
With control gear
Yes
Country of origin
China (CN)
Statistische Warennummer
andere elektrische Leuchten und Beleuchtungskörper, anderweitig weder genannt noch inbegriffen, mit LED-Lichtquelle, andere als Scheinwerfer, aus Kunststoffen (94054231)
REACH Indicator
No
