For further information, please refer to the data sheet!Weight
0,76 kg
Minimum order quantity
6 pieces
Order step
6 pieces
Weight
0,76 kg
Product group
Ceiling/wall light (EC002892)
Dimming DALI-2
No
Constant luminous flux control
No
Adjustable beam angle
No
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
Yes
Max. System performance
13,5 W
Color temperature
3.000 K
Protection class (IP)
IP44
Without dimming function
Yes
Width
202 mm
Height/depth
45 mm
Length
202 mm
Suitable for number of light sources
0
Outer diameter
202 mm
Version
other
Surface protection housing
powder-coated
Material of the housing
Aluminum
Design of the grid
other
Voltage type
AC
Nominal voltage
220 – 240 V
Operating device
EVG
Light distributor
Diffuser lens/optics/panel
Color consistency (McAdam ellipse)
SDCM6
Light emission
direct
Protection class
I
Rated ambient temperature according to IEC 62722-2-1
-20 – 40 °C
Luminaire luminous efficacy
37 lm/W
Rated luminous flux according to IEC 62722-2-1
480 lm
Light source
LED not replaceable
Type of wiring
Conclusion
Number of poles
3
Connection type
Screw terminal
Suitable for wall mounting
Yes
Suitable for surface mounting
Yes
With illuminant
Yes
With control gear
Yes
Country of origin
China (CN)
Statistische Warennummer
Lüster und andere elektrische Decken- und Wandleuchten, mit LED-Lichtquelle, aus anderen Stoffen als Kunststoff, keramischen Stoffen oder Glas (94051190)
REACH Indicator
No
Datenblatt
Suitable for pendant suspension
No
Suitable for ceiling mounting
No
Suitable for recessed mounting
No
Geeignet für Anbaumontage
Yes
Suitable for strip light configuration
No
Suitable for VDU workstations according to EN 12464-1
No
Suitable for number of light sources
0
Dimming 0-10 V
No
Dimming 1-10 V
No
DALI dimming
No
DMX dimming
No
Dimming DSI
No
Dimming potentiometer (device-integrated)
No
Dimmung GPRS
No
Dimming LineSwitch
No
Dimming manufacturer-specific
No
Dimming Mains voltage modulation
No
Dimming phase cut-off
No
Phase control dimming
No
RF dimming
No
Dimming Sine Wave Reduction
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming depending on the control gear
No
Bemessungsumgebungstemperatur nach IEC62722-2-1
-20 – 40 °C
Suitable for emergency lighting
No
Integrated emergency power supply
No
With motion detector
No
With light sensor
No
Covering the luminaire with thermal insulation material possible
No
Mit Luftschlitzen
No
Operation via Bluetooth
No
Housing color
gray
Cover material
Plastic opal
Energieeffizienzklasse der Lichtquelle nach EU-Richtlinie 2019/2015
nicht erforderlich
Max. Number of lights Circuit breaker C16
200
Impact resistance
IK07
Luminaire with limited surface temperature "D mark" according to EN 60598-2-24
No
Light color
white
Color rendering index CRI
80-89
Power factor
0,5
Photobiological safety according to EN 62471
RG0
Glare limitation (UGR)
25
Kompatibel mit Casambi
No
Erfüllt min. EIA Lebensdauerkriterium L90 (bei 50.000 h bei tq = 25 °C)
No
