02-4058075205413
31. October 2024
02-4058075206625
31. October 2024
02-4058075205581
For further information, please refer to the data sheet!Minimum order quantity
6 pieces
Order step
6 pieces
Weight
0,63 kg
Product group
Ceiling/wall light (EC002892)
Dimming DALI-2
No
Max. Number of lights Circuit breaker C16
200
Constant luminous flux control
No
Adjustable beam angle
No
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No
Housing color
white
Max. System performance
12,50 W
Color temperature
3.000,00 K
Protection class (IP)
IP44
Without dimming function
Yes
Width
91,00 mm
Height/depth
110,00 mm
Length
131 mm
Material of the housing
Aluminum
Voltage type
AC
Nominal voltage
220 – 240 V
Rated current
85 mA
Operating device
EVG
Light emission
direct
Rated service life L70/B50 at 25 °C
30.000 h
Color rendering index CRI
80-89
Impact resistance
IK03
Protection class
I
Rated ambient temperature according to IEC 62722-2-1
-20 – 40 °C
Luminaire luminous efficacy
75 lm/W
Rated luminous flux according to IEC 62722-2-1
980 lm
Type of wiring
Conclusion
Number of poles
3
Connection type
Screw terminal
Photobiological safety according to EN 62471
RG1
Suitable for wall mounting
Yes
Suitable for surface mounting
Yes
With illuminant
Yes
With control gear
Yes
Country of origin
China (CN)
Statistische Warennummer
Lüster und andere elektrische Decken- und Wandleuchten, mit LED-Lichtquelle, aus anderen Stoffen als Kunststoff, keramischen Stoffen oder Glas (94051190)
REACH Indicator
No
