02-4058075206625
31. October 2024
02-4058075206861
31. October 2024
02-4058075206847
For further information, please refer to the data sheet!Minimum order quantity
8 pieces
Order step
8 pieces
Weight
0,5 kg
Product group
Downlight/spotlight/floodlight (EC001744)
Suitable for wall mounting
No
Dimming DALI-2
No
Constant luminous flux control
No
Adjustable beam angle
No
IFTTT support available
No
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
Suitable for truss mounting
No
Suitable for platform/floor mounting
No
Suitable for busbar mounting
No
Suitable for clamp mounting
No
Suitable for cable system
No
Material of the housing
Aluminum
Brushed surface
No
Voltage type
AC
Nominal voltage
220 – 240 V
LED rated current with constant current
46 mA
Operating device
EVG
Without dimming function
Yes
Reflector
Without
Light emission
direct
Rated service life L70/B50 at 25 °C
25.000 h
Protection class (IP)
IP65
Impact resistance
IK03
Protection class
I
Rated ambient temperature according to IEC 62722-2-1
-20 – 45 °C
Max. System performance
10,00 W
Color temperature
3.000,00 K
Color rendering index CRI
80-89
Luminous flux
800,00 lm
Rated luminous flux according to IEC 62722-2-1
800 lm
Width
108,00 mm
Height/depth
292,00 mm
Length
44 mm
Type of wiring
Conclusion
Number of poles
3
Luminaire luminous efficacy
80 lm/W
Photobiological safety according to EN 62471
RG1
Suitable for surface mounting
Yes
With illuminant
Yes
With control gear
Yes
Country of origin
China (CN)
Statistische Warennummer
andere elektrische Leuchten und Beleuchtungskörper, anderweitig weder genannt noch inbegriffen, mit LED-Lichtquelle, andere als Scheinwerfer, aus anderen Stoffen als aus Kunststoffen (94054239)
REACH Indicator
Yes
