02-4058075214057
31. October 2024
02-4058075214170
31. October 2024
02-4058075214071
For further information, please refer to the data sheet!Minimum order quantity
6 pieces
Order step
6 pieces
Weight
0,48 kg
Product group
Ceiling/wall light (EC002892)
Dimming DALI-2
No
Constant luminous flux control
No
Adjustable beam angle
No
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No
Housing color
white
Max. System performance
12,00 W
Color temperature
3.000,00 K
Protection class (IP)
IP44
Without dimming function
Yes
Width
90,00 mm
Height/depth
160,00 mm
Length
55 mm
Suitable for number of light sources
0
Version
other
Surface protection housing
powder-coated
Material of the housing
Aluminum
Design of the grid
other
Voltage type
AC
Nominal voltage
220 – 240 V
Rated current
60 mA
Operating device
EVG
Light distributor
Diffuser lens/optics/panel
Color consistency (McAdam ellipse)
SDCM6
Light emission
direct
Rated service life L70/B50 at 25 °C
30.000 h
Protection class
I
Rated ambient temperature according to IEC 62722-2-1
-20 – 40 °C
Luminaire luminous efficacy
58 lm/W
Rated luminous flux according to IEC 62722-2-1
700 lm
Light source
LED not replaceable
Type of wiring
Conclusion
Number of poles
3
Connection type
Screw terminal
Suitable for wall mounting
Yes
Suitable for surface mounting
Yes
With illuminant
Yes
With control gear
Yes
Country of origin
China (CN)
Statistische Warennummer
Lüster und andere elektrische Decken- und Wandleuchten, mit LED-Lichtquelle, aus anderen Stoffen als Kunststoff, keramischen Stoffen oder Glas (94051190)
REACH Indicator
No
