Hocheffiziente Aussenwand-Sensorstrahler mit engem Ausstrahlungswinkel in innovativem optischen Design

SKU: 02-4058075228900
Datasheet: Download PDF
For further information, please refer to the data sheet!
Hocheffiziente Aussenwand-Sensorstrahler mit engem Ausstrahlungswinkel in innovativem optischen Design. Produkteigenschaften: 4 Einstellmöglichkeiten wählbar (Licht 6h permanent an, stand-by, Einschalten bei Bewegung oder Dämmerung). Verstellbarer Leuchtenkopf. Schutzart: IP55. Stoßfestigkeit: IK05. Schutzklasse: II. Produktvorteile: Kleine Strahler für präzise Ausleuchtung. Schwenkbarer Leuchtenkopf ermöglicht eine bedarfsgerechte Beleuchtung. Einfache und schnelle Installation. Anwendungsgebiete: Außenbereiche. Eingangsbereiche. Arkadengänge.
Weight
0,415 kg
Minimum order quantity

6 pieces

Order step

6 pieces

Weight

0,415 kg

Product group

Downlight/spotlight/floodlight (EC001744)

Suitable for wall mounting

Yes

Replaceable operating device

No

Dimming DALI-2

No

Constant luminous flux control

No

Adjustable color temperature

No

Adjustable luminous flux

Steps

Adjustable beam angle

No

IFTTT support available

Yes

Compatible with Apple HomeKit

No

Compatible with Google Assistant

No

Compatible with Amazon Alexa

No

Suitable for truss mounting

No

Suitable for platform/floor mounting

No

Suitable for busbar mounting

No

Suitable for clamp mounting

No

Suitable for cable system

No

Adjustability

Rotatable and swiveling

Housing color

white

Brushed surface

No

Voltage type

AC

Nominal voltage

220 – 240 V

LED rated current with constant current

86 mA

Operating device

EVG

Without dimming function

Yes

Reflector

Without

Light emission

direct

Rated service life L70/B50 at 25 °C

30.000 h

Protection class (IP)

IP55

Impact resistance

IK05

Protection class

II

Rated ambient temperature according to IEC 62722-2-1

-20 – 40 °C

Max. System performance

16 W

Color temperature

4.000 K

Color rendering index CRI

80-89

Luminous flux

1.500 lm

Rated luminous flux according to IEC 62722-2-1

1.500 lm

Width

58 mm

Height/depth

187 mm

Length

177 mm

Type of wiring

Conclusion

Luminaire luminous efficacy

86 lm/W

Photobiological safety according to EN 62471

RG1

Color consistency (McAdam ellipse)

SDCM6

Suitable for surface mounting

Yes

With motion detector

Yes

With light sensor

Yes

With illuminant

Yes

With control gear

Yes

RoHS applicable

Yes

Country of origin

China (CN)

Commodity code

Chandeliers and other electric ceiling and wall lights, with LED light source, made of plastic or ceramic materials (94051140)

REACH Indicator

No

Datenblatt
4058075228900_ENDURA_PRO_Spot_Sensor_16W_4000K_IP55_White_de.pdf4058075228900_tds_de.pdfasset-13048027-1.pdfasset-9171780.pdfasset-13082202-1.pdfasset-5945888.jpg
Geeignet für Anbaumontage

Yes

Suitable for recessed mounting

No

Suitable for pendant suspension

No

Suitable for ceiling mounting

No

Dimming depending on the control gear

No

Dimming 0-10 V

No

Dimming 1-10 V

No

DALI dimming

No

DMX dimming

No

Dimming DSI

No

Dimming potentiometer (device-integrated)

No

Dimmung GPRS

No

Dimming LineSwitch

No

Dimming manufacturer-specific

No

Dimming Mains voltage modulation

No

Dimming phase cut-off

No

Phase control dimming

No

Programmable dimming

No

RF dimming

No

Dimming Sine Wave Reduction

No

Dimming Touch and Dim

No

Dimming Zigbee

No

Dimming with push-button

No

Bemessungsumgebungstemperatur nach IEC62722-2-1

-20 – 40 °C

Integrated emergency power supply

No

Suitable for VDU workstations according to EN 12464-1

No

Covering the luminaire with thermal insulation material possible

No

Material of the housing

Plastic

Cover material

Plastic opal

Rated current

86 mA

Energieeffizienzklasse der Lichtquelle nach EU-Richtlinie 2019/2015

nicht erforderlich

Light color

white

Power factor

0,85

Number of poles

3

Luminaire with limited surface temperature "D mark" according to EN 60598-2-24

No

Operation via Bluetooth

No
