02-4058075300781
31. October 2024
02-4058075300903
31. October 2024
02-4058075300828
For further information, please refer to the data sheet!Minimum order quantity
6 pieces
Order step
6 pieces
Weight
1,485 kg
Product group
Ceiling/wall light (EC002892)
Dimming DALI-2
No
Max. Number of lights Circuit breaker C16
54
Adjustable beam angle
No
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No
Housing color
gray
Max. System performance
40,00 W
Color temperature
4.000,00 K
Protection class (IP)
IP65
Without dimming function
Yes
Width
77,00 mm
Height/depth
68,00 mm
Length
1.200 mm
Suitable for number of light sources
0
Version
other
Surface protection housing
untreated
Material of the housing
Plastic
Design of the grid
dull
Voltage type
AC
Nominal voltage
220 – 240 V
Rated current
220 mA
Operating device
EVG
Light distributor
Diffuser lens/optics/panel
Light emission
direct
Rated service life L70/B50 at 25 °C
50.000 h
Impact resistance
IK08
Protection class
I
Rated ambient temperature according to IEC 62722-2-1
-20 – 40 °C
Luminaire luminous efficacy
120 lm/W
Rated luminous flux according to IEC 62722-2-1
4.800 lm
Light source
LED not replaceable
Power factor
0,90
Type of wiring
Suitable for through-wiring
Number of poles
3
Connection type
Plug-in terminal
Photobiological safety according to EN 62471
RG0
Suitable for wall mounting
Yes
Suitable for ceiling mounting
Yes
Suitable for surface mounting
Yes
With illuminant
Yes
With control gear
Yes
Country of origin
China (CN)
Commodity code
Chandeliers and other electric ceiling and wall lights, with LED light source, made of plastic or ceramic materials (94051140)
REACH Indicator
No
