02-4058075436145
31. October 2024
02-4058075436237
31. October 2024
02-4058075436176
For further information, please refer to the data sheet!Minimum order quantity
10 pieces
Order step
10 pieces
Weight
0,501 kg
Product group
Light tube/tape (EC002706)
Constant luminous flux control
Yes
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No
Execution
Ribbon
Mounting type
Structure
Light source
LED not replaceable
Number of light sources per meter
120
Number of light sources per foot
36,00
Lamp wattage per meter
20,00 W
Luminous flux per meter
1.150 lm
Voltage type
DC
Lamp voltage
24,00 V
Beam angle
120 °
Rated service life L70/B50 at 25 °C
40.000 h
Protection class (IP)
IP66
Protection class (NEMA)
other
Max. System performance
98,00 W
Color temperature
4.000,00 K
Width
14,00 mm
Height/depth
5,00 mm
Length
5.000 mm
Smallest bending radius
30,00 mm
Length of the individual sections
100,00 mm
With end piece
No
With connection set
No
With protective cover
Yes
Self-adhesive
Yes
Number of poles
5
Conductor cross-section
0,50 mm²
Connection type
Plug-in terminal
Country of origin
China (CN)
Commodity code
Light-emitting diode modules (LED modules) (85395100)
REACH Indicator
No
