For further information, please refer to the data sheet!Weight
1,34 kg
Suitable for wall mounting
Yes
Suitable for pendant suspension
No
Suitable for ceiling mounting
Yes
Suitable for recessed mounting
No
Suitable for surface mounting
Yes
Suitable for strip light configuration
No
Suitable for VDU workstations according to EN 12464-1
No
With illuminant
Yes
Material of the housing
Aluminum
Housing color
white
Design of the grid
dull
Voltage type
AC
Nominal voltage
220 – 240 V
Operating device
EVG
With control gear
Yes
Dimming 0-10 V
No
Dimming 1-10 V
No
Dimming DALI-2
No
DALI dimming
No
DMX dimming
No
Dimming DSI
No
Dimming potentiometer (device-integrated)
No
Dimming LineSwitch
No
Dimming manufacturer-specific
No
Dimming Mains voltage modulation
No
Dimming phase cut-off
No
Phase control dimming
No
RF dimming
No
Dimming Sine Wave Reduction
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Without dimming function
Yes
Color consistency (McAdam ellipse)
SDCM6
Light emission
direct
Energieeffizienzklasse der Lichtquelle nach EU-Richtlinie 2019/2015
nicht erforderlich
Rated service life L70/B50 at 25 °C
25.000 h
Protection class (IP)
IP20
Protection class
II
Luminaire with limited surface temperature "D mark" according to EN 60598-2-24
No
Rated ambient temperature according to IEC 62722-2-1
-20 – 40 °C
Suitable for emergency lighting
No
Integrated emergency power supply
No
With motion detector
No
With light sensor
No
Covering the luminaire with thermal insulation material possible
No
Mit Luftschlitzen
No
Max. System performance
19 W
Luminaire luminous efficacy
75 lm/W
Rated luminous flux according to IEC 62722-2-1
1.600 lm
Light color
white
Color temperature
3.000 K
Color rendering index CRI
80-89
Power factor
0,9
Constant luminous flux control
No
Height/depth
65 mm
Length
300 mm
Outer diameter
300 mm
Type of wiring
Conclusion
Number of poles
2
Connection type
Plug-in terminal
Adjustable beam angle
No
Operation via Bluetooth
No
Kompatibel mit Casambi
No
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
Yes
Erfüllt min. EIA Lebensdauerkriterium L90 (bei 50.000 h bei tq = 25 °C)
No
