02-4058075474253
31. October 2024
02-4058075474628
31. October 2024
02-4058075474604
For further information, please refer to the data sheet!Minimum order quantity
12 pieces
Order step
12 pieces
Weight
0,38 kg
Product group
Downlight/spotlight/floodlight (EC001744)
Suitable for wall mounting
Yes
Dimming DALI-2
No
Constant luminous flux control
No
Adjustable beam angle
No
IFTTT support available
No
Compatible with Apple HomeKit
No
Compatible with Google Assistant
Yes
Compatible with Amazon Alexa
Yes
Suitable for truss mounting
No
Suitable for platform/floor mounting
No
Suitable for busbar mounting
No
Suitable for clamp mounting
No
Suitable for cable system
No
Light source
LED not replaceable
Suitable for number of light sources
0
Version
Without
Material of the housing
Aluminum
Brushed surface
No
Voltage type
AC
Nominal voltage
220 – 240 V
Operating device
EVG
Without dimming function
No
Light emission
direct
Distortion factor (THD)
40
Rated service life L70/B50 at 25 °C
30.000 h
Protection class (IP)
IP65
Impact resistance
IK05
Protection class
I
Rated ambient temperature according to IEC 62722-2-1
-20 – 40 °C
Max. System performance
10,00 W
Color temperature
3.000,00 K
Color rendering index CRI
80-89
Luminous flux
800,00 lm
Rated luminous flux according to IEC 62722-2-1
800 lm
Width
125,00 mm
Height/depth
28,00 mm
Length
152 mm
Type of wiring
Conclusion
Number of poles
3
Connection type
Plug-in terminal
Luminaire luminous efficacy
63 lm/W
Suitable for surface mounting
Yes
With illuminant
Yes
With control gear
Yes
Country of origin
China (CN)
Statistische Warennummer
andere elektrische Leuchten und Beleuchtungskörper, anderweitig weder genannt noch inbegriffen, mit LED-Lichtquelle, andere als Scheinwerfer, aus anderen Stoffen als aus Kunststoffen (94054239)
REACH Indicator
No
