For further information, please refer to the data sheet!Minimum order quantity
12 pieces
Order step
12 pieces
Weight
0,273 kg
Product group
Ceiling/wall light (EC002892)
Dimming DALI-2
No
Constant luminous flux control
No
Adjustable beam angle
No
Compatible with Apple HomeKit
No
Compatible with Google Assistant
Yes
Compatible with Amazon Alexa
Yes
IFTTT support available
No
Housing color
white
Max. System performance
22,00 W
Color temperature
3.000,00 – 6.500,00 K
Protection class (IP)
IP20
Without dimming function
No
Height/depth
35,00 mm
Length
150 mm
Outer diameter
225 mm
Installation height/depth
35 mm
Installation diameter
200,00 mm
Design of the grid
dull
Voltage type
AC
Nominal voltage
220 – 240 V
Rated current
150 mA
Rated service life L70/B50 at 25 °C
25.000 h
Color rendering index CRI
80-89
Impact resistance
IK03
Protection class
II
Rated ambient temperature according to IEC 62722-2-1
-20 – 40 °C
Luminaire luminous efficacy
90 lm/W
Rated luminous flux according to IEC 62722-2-1
2.000 lm
Type of wiring
Conclusion
Number of poles
2
Connection type
Screw terminal
Photobiological safety according to EN 62471
RG0
Suitable for recessed mounting
Yes
Suitable for surface mounting
Yes
With illuminant
Yes
With control gear
Yes
Country of origin
China (CN)
Commodity code
Chandeliers and other electric ceiling and wall lights, with LED light source, made of plastic or ceramic materials (94051140)
REACH Indicator
No
