02-4058075573291
31. October 2024
02-4058075573390
31. October 2024
02-4058075573314
For further information, please refer to the data sheet!Minimum order quantity
6 pieces
Order step
6 pieces
Weight
0,053 kg
Product group
Ceiling/wall light (EC002892)
Dimming DALI-2
No
Constant luminous flux control
No
Adjustable beam angle
No
Compatible with Apple HomeKit
No
Compatible with Google Assistant
Yes
Compatible with Amazon Alexa
Yes
IFTTT support available
No
Housing color
white
Max. System performance
4,50 W
Color temperature
2.700,00 – 6.500,00 K
Protection class (IP)
IP20
Without dimming function
No
Height/depth
70,00 mm
Outer diameter
86 mm
Installation height/depth
70 mm
Installation diameter
70,00 mm
Design of the grid
dull
Voltage type
AC
Nominal voltage
220 – 240 V
Rated current
60 mA
Color consistency (McAdam ellipse)
SDCM6
Rated service life L70/B50 at 25 °C
25.000 h
Color rendering index CRI
80-89
Impact resistance
IK03
Protection class
II
Rated ambient temperature according to IEC 62722-2-1
-20 – 40 °C
Luminaire luminous efficacy
80 lm/W
Rated luminous flux according to IEC 62722-2-1
300 lm
Type of wiring
Conclusion
Number of poles
2
Connection type
Screw terminal
Photobiological safety according to EN 62471
RG0
Suitable for recessed mounting
Yes
Suitable for surface mounting
Yes
With illuminant
Yes
With control gear
Yes
Country of origin
China (CN)
Statistische Warennummer
andere elektrische Leuchten und Beleuchtungskörper, anderweitig weder genannt noch inbegriffen, mit LED-Lichtquelle, andere als Scheinwerfer, aus Kunststoffen (94054231)
REACH Indicator
No
