For further information, please refer to the data sheet!Minimum order quantity
3 pieces
Order step
3 pieces
Weight
3,8 kg
Product group
Ceiling/wall light (EC002892)
Dimming DALI-2
No
Max. Number of lights Circuit breaker C16
5
Constant luminous flux control
No
Adjustable beam angle
No
Compatible with Apple HomeKit
No
Compatible with Google Assistant
Yes
Compatible with Amazon Alexa
Yes
IFTTT support available
No
Housing color
white
Max. System performance
32,00 W
Color temperature
2.700,00 – 6.500,00 K
Protection class (IP)
IP20
Without dimming function
No
Width
485,00 mm
Height/depth
80,00 mm
Length
485 mm
Design of the grid
dull
Voltage type
AC
Nominal voltage
220 – 240 V
Rated current
140 mA
Rated service life L70/B50 at 25 °C
30.000 h
Impact resistance
IK03
Protection class
I
Rated ambient temperature according to IEC 62722-2-1
-20 – 45 °C
Luminaire luminous efficacy
233 lm/W
Rated luminous flux according to IEC 62722-2-1
1.800 lm
Power factor
0,90
Type of wiring
Conclusion
Number of poles
3
Connection type
Screw terminal
Photobiological safety according to EN 62471
RG0
Suitable for wall mounting
Yes
Suitable for surface mounting
Yes
With illuminant
Yes
With control gear
Yes
Country of origin
China (CN)
Statistische Warennummer
Lüster und andere elektrische Decken- und Wandleuchten, mit LED-Lichtquelle, aus anderen Stoffen als Kunststoff, keramischen Stoffen oder Glas (94051190)
REACH Indicator
Yes
