02-4058075651753
31. October 2024
02-4058075651852
31. October 2024
02-4058075651814
For further information, please refer to the data sheet!Minimum order quantity
6 pieces
Order step
6 pieces
Weight
0,44 kg
Product group
Ceiling/wall light (EC002892)
Dimming DALI-2
No
Max. Number of lights Circuit breaker C16
39
Constant luminous flux control
No
Adjustable beam angle
No
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No
Housing color
white
Max. System performance
15,50 W
Color temperature
3.000,00 K
Protection class (IP)
IP44
Without dimming function
Yes
Height/depth
83,00 mm
Outer diameter
300 mm
Surface protection housing
powder-coated
Material of the housing
Aluminum
Design of the grid
dull
Voltage type
AC
Nominal voltage
220 – 240 V
Rated current
120 mA
Color consistency (McAdam ellipse)
SDCM6
Light emission
indirect
Rated service life L70/B50 at 25 °C
25.000 h
Color rendering index CRI
80-89
Impact resistance
IK03
Protection class
I
Rated ambient temperature according to IEC 62722-2-1
-20 – 40 °C
Luminaire luminous efficacy
80 lm/W
Rated luminous flux according to IEC 62722-2-1
1.100 lm
Type of wiring
Conclusion
Number of poles
2
Connection type
Plug-in terminal
Photobiological safety according to EN 62471
RG0
Glare limitation (UGR)
22
Suitable for wall mounting
Yes
Suitable for ceiling mounting
Yes
Suitable for surface mounting
Yes
With illuminant
Yes
With control gear
Yes
With motion detector
Yes
With light sensor
Yes
Country of origin
China (CN)
Statistische Warennummer
Lüster und andere elektrische Decken- und Wandleuchten, mit LED-Lichtquelle, aus anderen Stoffen als Kunststoff, keramischen Stoffen oder Glas (94051190)
REACH Indicator
Yes
