02-4058075763425
31. October 2024
02-4058075764248
31. October 2024
02-4058075763487
For further information, please refer to the data sheet!Minimum order quantity
4 pieces
Order step
4 pieces
Weight
0,95 kg
Product group
Ceiling/wall light (EC002892)
Dimming DALI-2
No
Constant luminous flux control
No
Adjustable beam angle
No
Compatible with Apple HomeKit
No
Compatible with Google Assistant
Yes
Compatible with Amazon Alexa
Yes
IFTTT support available
No
Max. System performance
16,00 W
Color temperature
3.000,00 K
Protection class (IP)
IP44
Without dimming function
No
Width
130,00 mm
Height/depth
135,00 mm
Length
250 mm
Suitable for number of light sources
0
Version
other
Design of the grid
dull
Voltage type
AC
Nominal voltage
220 – 240 V
Rated current
77 mA
Color consistency (McAdam ellipse)
SDCM6
Rated service life L70/B50 at 25 °C
30.000 h
Impact resistance
IK05
Protection class
II
Rated ambient temperature according to IEC 62722-2-1
-20 – 40 °C
Luminaire luminous efficacy
56 lm/W
Rated luminous flux according to IEC 62722-2-1
900 lm
Light source
LED not replaceable
Type of wiring
Conclusion
Connection type
Plug-in terminal
Distortion factor (THD)
20
Photobiological safety according to EN 62471
RG0
Suitable for wall mounting
Yes
Suitable for surface mounting
Yes
With illuminant
Yes
With control gear
Yes
With motion detector
Yes
Country of origin
China (CN)
Statistische Warennummer
Lüster und andere elektrische Decken- und Wandleuchten, mit LED-Lichtquelle, aus anderen Stoffen als Kunststoff, keramischen Stoffen oder Glas (94051190)
REACH Indicator
No
