02-4058075769335
31. October 2024
02-4058075769397
31. October 2024
02-4058075769359
For further information, please refer to the data sheet!Minimum order quantity
4 pieces
Order step
4 pieces
Weight
2,8 kg
Product group
Ceiling/wall light (EC002892)
Dimming DALI-2
No
Max. Number of lights Circuit breaker C16
9
Constant luminous flux control
No
Adjustable beam angle
No
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No
Housing color
black
Max. System performance
45,00 W
Color temperature
3.000,00 K
Protection class (IP)
IP65
Without dimming function
Yes
Height/depth
125,00 mm
Suitable for number of light sources
0
Outer diameter
250 mm
Version
other
Surface protection housing
powder-coated
Material of the housing
Aluminum
Design of the grid
other
Voltage type
AC
Nominal voltage
220 – 240 V
Rated current
220 mA
Light distributor
Diffuser lens/optics/panel
Color consistency (McAdam ellipse)
SDCM6
Light emission
direct
Rated service life L70/B50 at 25 °C
100.000 h
Rated service life L80/B10 at 25 °C
70.000 h
Rated service life L90/B10 at 25 °C
60.000 h
Impact resistance
IK06
Protection class
I
Rated ambient temperature according to IEC 62722-2-1
-20 – 40 °C
Luminaire luminous efficacy
105 lm/W
Rated luminous flux according to IEC 62722-2-1
4.725 lm
Light source
LED not replaceable
Type of wiring
Conclusion
Number of poles
3
Connection type
Plug-in terminal
Photobiological safety according to EN 62471
RG0
Suitable for wall mounting
Yes
Suitable for ceiling mounting
Yes
Suitable for surface mounting
Yes
With illuminant
Yes
With control gear
Yes
Country of origin
China (CN)
Statistische Warennummer
andere elektrische Leuchten und Beleuchtungskörper, anderweitig weder genannt noch inbegriffen, mit LED-Lichtquelle, andere als Scheinwerfer, aus anderen Stoffen als aus Kunststoffen (94054239)
REACH Indicator
No
