SPOT COMBO FIX V 5.5W CPS 60DEG IP65 WT

SKU: 02-4099854092701
Datasheet: Download PDF
For further information, please refer to the data sheet!
Coverable spot with CCT and Power Select (CPS) in fixed design. Product features: Colour temperature switch (CCT): 2700 K, 3000 K, 4000 K. Power Select option available to choose between two luminous fluxes. Degree of protection: IP65. Housing material: Polycarbonate (PC). Product advantages: Adjustment of the color temperature via a switch on the back of the spot. Power select: Adjust the brightness via a switch on the driver. Can be covered with most insulating materials. 5-year warranty. Areas of application: Direct replacement for recessed spotlights with halogen lamps. General lighting. Hotel rooms and corridors. Bars, Restaurants. Living. Technical equipment: Already equipped with a white round ring. Additional cover rings available separately in round and square shapes and in different colours.
Minimum order quantity

20 pieces

Order step

20 pieces

Weight

0,177 kg

Product group

Downlight/spotlight/floodlight (EC001744)

Suitable for wall mounting

No

Replaceable operating device

No

Dimming DALI-2

No

Constant luminous flux control

No

Adjustable color temperature

Steps

Adjustable luminous flux

Steps

Adjustable beam angle

No

Installation diameter

68 mm

Max. Number of lights Circuit breaker C16

79

IFTTT support available

No

Compatible with Apple HomeKit

No

Compatible with Google Assistant

No

Compatible with Amazon Alexa

No

Suitable for truss mounting

No

Suitable for platform/floor mounting

No

Suitable for busbar mounting

No

Suitable for clamp mounting

No

Suitable for cable system

No

Adjustability

not adjustable

Surface protection

powder-coated

Housing color

white

Brushed surface

No

Voltage type

AC

Nominal voltage

220 – 240 V

LED rated current with constant current

43 mA

Operating device

LED control gear, current-controlled

Without dimming function

Yes

Reflector

high gloss

Light distributor

Focus lens

Light distribution

symmetrical

Light emission

direct

Rated service life L70/B50 at 25 °C

50.000 h

Rated service life L80/B10 at 25 °C

39.000 h

Protection class (IP)

IP65

Impact resistance

IK03

Protection class

II

Rated ambient temperature according to IEC 62722-2-1

-20 – 40 °C

Max. System performance

5,50 W

Color temperature

2.700,00 K

Luminous flux

600,00 lm

Rated luminous flux according to IEC 62722-2-1

600 lm

Height/depth

48,00 mm

Outer diameter

81,5 mm

Installation height/depth

48 mm

Type of wiring

Suitable for through-wiring

Number of poles

2

Luminaire luminous efficacy

109 lm/W

Photobiological safety according to EN 62471

RG1

Suitable for surface mounting

Yes

Suitable for recessed mounting

Yes

Suitable for ceiling mounting

Yes

With illuminant

Yes

With control gear

Yes

Covering the luminaire with thermal insulation material possible

Yes

RoHS applicable

Yes

Country of origin

China (CN)

Statistische Warennummer

andere elektrische Leuchten und Beleuchtungskörper, anderweitig weder genannt noch inbegriffen, mit LED-Lichtquelle, andere als Scheinwerfer, aus anderen Stoffen als aus Kunststoffen (94054239)

REACH Indicator

No
