VLED DOWNLIGHT - Round recessed luminaires rigid white 18W 120° 3000K CRI80 DWL051
For further information, please refer to the data sheet!Weight
0,22 kg
Product group
Downlight/spotlight/floodlight (EC001744)
Suitable for wall mounting
No
Dimming DALI-2
No
Constant luminous flux control
No
Adjustable beam angle
No
Installation diameter
100 mm
IFTTT support available
No
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
Suitable for truss mounting
No
Suitable for platform/floor mounting
No
Suitable for busbar mounting
No
Suitable for clamp mounting
No
Suitable for cable system
No
Light source
LED not replaceable
Suitable for number of light sources
1
Version
Without
Material of the housing
Plastic
Surface protection
powder-coated
Housing color
white
Cover material
Plastic opal
Brushed surface
No
Voltage type
AC
Nominal voltage
220 – 240 V
Operating device
LED control gear, current-controlled
Without dimming function
Yes
Reflector
Without
Light distributor
Diffuser lens/optics/panel
Light distribution
symmetrical
Beam angle
Extremely wide beam >80°
Rated service life L70/B50 at 25 °C
36.000 h
Protection class (IP)
IP20
Protection class
II
Max. System performance
18,00 W
Light color
white
Color temperature
3.000,00 K
Color rendering index CRI
80-89
Outer diameter
190 mm
Installation height/depth
100 mm
Type of wiring
Conclusion
Number of poles
2
Connection type
Screw terminal
Luminaire luminous efficacy
82 lm/W
Glow wire test according to IEC 60695-2-11
Without
Color consistency (McAdam ellipse)
SDCM6
Reflector color
other
Suitable for recessed mounting
Yes
Suitable for ceiling mounting
Yes
With illuminant
Yes
With control gear
Yes
Country of origin
China (CN)
Commodity code
Chandeliers and other electric ceiling and wall lights, with LED light source, made of plastic or ceramic materials (94051140)
