EUTRAC Track 3-Phase Mounted Rail BASIC 2000mm, black 15-202

SKU: 111-15-202
Datasheet: Download PDF
For further information, please refer to the data sheet!
EUTRAC BASIC 5-conductor busbar (L1/L2/L3/N/earth) for three circuits 16A/440V, for ceiling, wall and pendant mounting.Consisting of an extruded aluminium profile and two rigid extruded beam profiles made of high-strength electrical insulation material, each with two embedded copper conductors with a cross-section of 3.3 mm² for three independent switchable circuits, grounded by the aluminium profile. Easy to cut to size on site with a standard saw, punched slotted holes for fastening. 2000mm, black
Manufacturer

EUTRAC Busbars GmbH

Product group

Conductor rail (EC000101)

Number of groups/phases

3

Nominal voltage

220 – 240 V

Max. electrical load capacity per phase

16 W

Shape

rectangular

Material

Aluminum

Finish of the surface

dull

Color

black

Bendable

No

Length

2.000 mm

Width

31,00 mm

Height

38,00 mm

Protection class

I

Suitable for pendant suspension

Yes

Suitable for surface mounting

Yes

Country of origin

Italy (IT)

Commodity code

Prefabricated busbar trunking systems for electrical cables, for a voltage of 1000V or less (85369001)

REACH Indicator

Yes
