LED downlight swivel, roundCENTURY 65 black 3W 40° 3000K CRI80 AA81037.02.91
31. October 2024
LED surface-mounted luminaire rigid, topCENTURY 320 M black 20W 50° 3000K CRI80 AA81053.02.91
31. October 2024
LED recessed luminaire swivel, roundCENTURY 68 black 6W 36° 00K CRI80 AA81038.02.91
For further information, please refer to the data sheet!Weight
0,22 kg
Product group
Downlight/spotlight/floodlight (EC001744)
Suitable for truss mounting
No
Suitable for platform/floor mounting
No
Suitable for busbar mounting
No
Suitable for clamp mounting
No
Suitable for cable system
No
Light source
LED not replaceable
Suitable for number of light sources
1
Version
Without
Material of the housing
Aluminum
Surface protection
powder-coated
Housing color
black
Cover material
Transparent plastic
Brushed surface
No
Voltage type
AC
Nominal voltage
220 – 240 V
Operating device
LED control gear, current-controlled
Without dimming function
Yes
Reflector
high gloss
Light distributor
Reflector
Light distribution
symmetrical
Beam angle
medium beam 21-40°
Light emission
direct
Energy efficiency class of the permanently installed light source
A++, A+, A (LED)
Rated service life L80/B10 at 25 °C
50.000 h
Protection class (IP)
IP20
Protection class
I
Rated ambient temperature according to IEC 62722-2-1
-20 – 25 °C
Max. System performance
6,00 W
Light color
white
Color temperature
3.000,00 K
Color rendering index CRI
80-89
Luminous flux
520,00 lm
Outer diameter
80 mm
Installation height/depth
75 mm
Type of wiring
Conclusion
Number of poles
2
Connection type
Plug-in terminal
Glow wire test according to IEC 60695-2-11
Without
Color consistency (McAdam ellipse)
SDCM3
Suitable for recessed mounting
Yes
Suitable for ceiling mounting
Yes
With illuminant
Yes
With control gear
Yes
Dimming depending on the control gear
Yes
Country of origin
China (CN)
