LED Aufbauleuchte starr, topCENTURY 320 M schwarz 20W 50° 3000K CRI80 AA81053.02.91

LED surface-mounted luminaire rigid, topCENTURY 320 M black 20W 50° 3000K CRI80 AA81053.02.91

SKU: 733-AA81053.02.91

Datasheet: Download PDF

For further information, please refer to the data sheet!

Unobtrusive medium-sized LED surface-mounted ceiling luminaire for architectural accents. Housing made of aluminum. Clear protective glass. Prismatic reflector for optimal light distribution. Color tolerance 3 SDCM. Luminous flux decrease after 50,000h L80/B10. Integrated, non-dimmable control gear. Net 1870lm. 3-year warranty.

Weight

0,9 kg

Weight

0,9 kg

Product group

Ceiling/wall light (EC002892)

Housing color

black

Max. System performance

20 W

Color temperature

3.000 K

Beam angle

wide beam 41-80°

Protection class (IP)

IP20

Without dimming function

Yes

Height/depth

120 mm

Suitable for number of light sources

Outer diameter

125 mm

Material of the housing

Aluminum

Cover material

Transparent glass

Design of the grid

Without

Voltage type

Nominal voltage

220 – 240 V

Operating device

LED control gear, current-controlled

Light distributor

Reflector

Light distribution

symmetrical

Light emission

direct

Energy efficiency class of the permanently installed light source

A++, A+, A (LED)

Rated service life L80/B10 at 25 °C

50.000 h

Color rendering index CRI

80-89

Protection class

Rated ambient temperature according to IEC 62722-2-1

-20 – 25 °C

Glow wire test according to IEC 60695-2-11

Without

Light color

white

Light source

LED not replaceable

Type of wiring

Conclusion

Number of poles

Connection type

Screw terminal

Suitable for wall mounting

Yes

Suitable for ceiling mounting

Yes

Suitable for surface mounting

Yes

With illuminant

Yes

With control gear

Yes

Dimming depending on the control gear

Yes

Country of origin

China (CN)

Datenblatt

AA81053.02.91.pdf ausschreibungstext_aa81053_02_91.txt declaration_rohs_md36-3.pdf

Suitable for pendant suspension

Suitable for recessed mounting

Geeignet für Anbaumontage

Yes

Suitable for strip light configuration

Suitable for VDU workstations according to EN 12464-1

Suitable for number of light sources

Dimming 0-10 V

Dimming 1-10 V

DALI dimming

DMX dimming

Dimming DSI

Dimmung Potenziometer (geräteintegriert)

Dimmung GPRS

Dimming LineSwitch

Dimming manufacturer-specific

Dimming Mains voltage modulation

Dimming phase cut-off

Phase control dimming

Programmable dimming

RF dimming

Dimming Sine Wave Reduction

Dimming Touch and Dim

Dimming Zigbee

Dimming with push-button

Leuchte mit begrenzter Oberflächentemperatur "D-Zeichen"

Bemessungsumgebungstemperatur nach IEC62722-2-1

-20 – 25 °C

Suitable for emergency lighting

With motion detector

With light sensor

Mit Luftschlitzen
