LED Aufbauleuchte linear, lineCENTURY 2 XS weiss 4W 180° 3000K CRI80 AA81695.00.91

LED surface-mounted luminaire linear, lineCENTURY 2 XS white 4W 180° 3000K CRI80 AA81695.00.91

SKU: 786-AA81695.00.91

Datasheet: Download PDF

For further information, please refer to the data sheet!

Compact and unobtrusive LED light strip for shelves, base cabinets, backlighting and general lighting in various lengths. Polycarbonate housing. Mounting accessories included: 30 cm extension cable ; 180cm power cord; Mounting bracket. Small size. Integrated, non-dimmable control gear. Net 440lm. 3-year warranty.

Weight

0,09 kg

Weight

0,09 kg

Product group

Ceiling/wall light (EC002892)

Housing color

white

Max. System performance

4 W

Color temperature

3.000 K

Beam angle

Extremely wide beam >80°

Protection class (IP)

IP44

Without dimming function

Yes

Width

20 mm

Height/depth

36 mm

Length

366 mm

Material of the housing

Plastic

Cover material

Plastic opal

Design of the grid

Without

Voltage type

Nominal voltage

220 – 240 V

Operating device

LED control gear, current-controlled

Light distributor

other

Light distribution

symmetrical

Light emission

direct

Energy efficiency class of the permanently installed light source

A++, A+, A (LED)

Color rendering index CRI

80-89

Protection class

Rated ambient temperature according to IEC 62722-2-1

-20 – 25 °C

Glow wire test according to IEC 60695-2-11

Without

Luminaire luminous efficacy

110 lm/W

Light color

white

Light source

LED not replaceable

Type of wiring

Conclusion

Number of poles

Connection type

Flat plug

Suitable for wall mounting

Yes

Suitable for ceiling mounting

Yes

Suitable for surface mounting

Yes

With illuminant

Yes

With control gear

Yes

Dimming depending on the control gear

Yes

Country of origin

China (CN)

Datenblatt

AA81695.00.91.pdf ausschreibungstext_aa81695_00_91.txt declaration_rohs_md36-1.pdf

Suitable for strip light configuration

Yes

Suitable for pendant suspension

Suitable for recessed mounting

Geeignet für Anbaumontage

Yes

Suitable for VDU workstations according to EN 12464-1

Dimming 0-10 V

Dimming 1-10 V

DALI dimming

DMX dimming

Dimming DSI

Dimmung Potenziometer (geräteintegriert)

Dimmung GPRS

Dimming LineSwitch

Dimming manufacturer-specific

Dimming Mains voltage modulation

Dimming phase cut-off

Phase control dimming

Programmable dimming

RF dimming

Dimming Sine Wave Reduction

Dimming Touch and Dim

Dimming Zigbee

Dimming with push-button

Leuchte mit begrenzter Oberflächentemperatur "D-Zeichen"

Bemessungsumgebungstemperatur nach IEC62722-2-1

-20 – 25 °C

Suitable for emergency lighting

With motion detector

With light sensor

Mit Luftschlitzen
