LED surface-mounted luminaire linear, lineCENTURY 2 XS white 4W 180° 4000K CRI80 AA81695.00.92
For further information, please refer to the data sheet!Weight
0,09 kg
Product group
Ceiling/wall light (EC002892)
Housing color
white
Max. System performance
4,00 W
Color temperature
4.000,00 K
Beam angle
Extremely wide beam >80°
Protection class (IP)
IP44
Without dimming function
Yes
Width
20,00 mm
Height/depth
36,00 mm
Length
366 mm
Material of the housing
Plastic
Cover material
Plastic opal
Design of the grid
Without
Voltage type
AC
Nominal voltage
220 – 240 V
Operating device
LED control gear, current-controlled
Light distributor
other
Light distribution
symmetrical
Light emission
direct
Energy efficiency class of the permanently installed light source
A++, A+, A (LED)
Color rendering index CRI
80-89
Protection class
II
Rated ambient temperature according to IEC 62722-2-1
-20 – 25 °C
Glow wire test according to IEC 60695-2-11
Without
Luminaire luminous efficacy
120 lm/W
Light color
white
Light source
LED not replaceable
Type of wiring
Conclusion
Number of poles
2
Connection type
–
Suitable for wall mounting
Yes
Suitable for ceiling mounting
Yes
Suitable for surface mounting
Yes
With illuminant
Yes
With control gear
Yes
Dimming depending on the control gear
Yes
Country of origin
China (CN)
