LED surface-mounted luminaire linear, lineCENTURY 2 M white 12W 180° 3000K CRI80 AA81697.00.91

EU-Energielabel für dieses Produkt
SKU: 786-AA81697.00.91
For further information, please refer to the data sheet!
Compact and unobtrusive LED light strip for shelves, base cabinets, backlighting and general lighting in various lengths. Polycarbonate housing. Mounting accessories included: 30 cm extension cable ; 180cm power cord; Mounting bracket. Small size. Integrated, non-dimmable control gear. Net 1300lm. 3-year warranty.
Weight
0,17 kg
Dimensions
22 × 892 × 36 cm
Length

892 mm

Width

20 mm

Height

36 mm

Volume

706,464 cm³ (0,71 l)

Weight

0,17 kg

Product group

Ceiling/wall light (EC002892)

Housing color

white

Max. System performance

12 W

Color temperature

3.000 K

Beam angle

Extremely wide beam >80°

Protection class (IP)

IP44

Without dimming function

Yes

Height/depth

36 mm

Suitable for number of light sources

1

Material of the housing

Plastic

Cover material

Plastic opal

Design of the grid

Without

Voltage type

AC

Nominal voltage

V

Operating device

LED control gear, current-controlled

Light distributor

Diffuser lens/optics/panel

Light distribution

symmetrical

Light emission

direct

Color rendering index CRI

80-89

Protection class

II

Rated ambient temperature according to IEC 62722-2-1

0,02 °C

Glow wire test according to IEC 60695-2-11

Without

Luminaire luminous efficacy

108 lm/W

Rated luminous flux according to IEC 62722-2-1

1.300 lm

Light color

white

Light source

LED not replaceable

Type of wiring

with through-wiring

Number of poles

2

Connection type

Flat plug

Suitable for wall mounting

Yes

Suitable for ceiling mounting

Yes

Suitable for surface mounting

Yes

With illuminant

Yes

With control gear

Yes

Suitable for strip light configuration

Yes

CE mark

Yes

Suitable for pendant suspension

No

Suitable for recessed mounting

No

Geeignet für Anbaumontage

Yes

Suitable for VDU workstations according to EN 12464-1

No

Suitable for number of light sources

1

Dimming 0-10 V

No

Dimming 1-10 V

No

DALI dimming

No

DMX dimming

No

Dimming DSI

No

Dimmung Potenziometer (geräteintegriert)

No

Dimmung GPRS

No

Dimming LineSwitch

No

Dimming manufacturer-specific

No

Dimming Mains voltage modulation

No

Dimming phase cut-off

No

Phase control dimming

No

Programmable dimming

No

RF dimming

No

Dimming Sine Wave Reduction

No

Dimming Touch and Dim

No

Dimming Zigbee

No

Dimming with push-button

No

Dimming depending on the control gear

No

Leuchte mit begrenzter Oberflächentemperatur "D-Zeichen"

No

Bemessungsumgebungstemperatur nach IEC62722-2-1

0,02 °C

Suitable for emergency lighting

No

With motion detector

No

With light sensor

No

Abdeckung der Leuchte mit Wärmedämm-Material möglich

No

Mit Luftschlitzen

No
