roundCENTURY 360 - Round recessed luminaires rotatable-swivel white 8W 36° 3000K CRI90 AA81219.00.91
31. October 2024
roundCENTURY 360 - Round recessed luminaires rotatable-swivel black 8W 36° 3000K CRI90 AA81219.02.91
31. October 2024

roundCENTURY 360 - Round recessed luminaires rotatable-swivel white 8W 36° 1800-3000K CRI90 AA81219.00.62

EU-Energielabel für dieses Produkt
SKU: 854-AA81219.00.62
Datasheet: Download PDF
For further information, please refer to the data sheet!
Small, universal LED recessed luminaire for retail and architecture. Mounting directly in the insulation layer up to the moisture barrier. No built-in box required, fits into various ceiling cutouts 68-83mm. Die-cast aluminum housing. Highly efficient multi-mirror reflector, integrated protective glass. Rotation range 360°. Color tolerance < 3 SDCM. Swivel range 30°. Color shift after 50,000h 4 SDCM. Luminous flux decrease after 50,000h L80/B10. Separate control gear dimmable by means of a trailing edge, incl. quick connector. 5-year warranty. Dim to warm 1-100%. Color Temperature Range 1800K-3000K
Weight
0,32 kg
Family

roundCENTURY 360

Weight

0,32 kg

Product group

Downlight/spotlight/floodlight (EC001744)

Suitable for wall mounting

No

Replaceable operating device

Yes

Dimming DALI-2

No

Luminous flux maintenance with average service life 50,000 h at 25 °C ambient temperature

80 %

Failure rate with average service life of 50,000 h at 25 °C ambient temperature (tq)

20 %

Constant luminous flux control

No

Adjustable color temperature

No

Adjustable luminous flux

No

Adjustable beam angle

No

Stroboscopic effect value SVM

0,4

Installation diameter

68 – 83 mm

Max. Number of lights Circuit breaker C16

81

IFTTT support available

No

Compatible with Apple HomeKit

No

Compatible with Google Assistant

No

Compatible with Amazon Alexa

No

Suitable for truss mounting

No

Suitable for platform/floor mounting

No

Suitable for busbar mounting

No

Suitable for clamp mounting

No

Suitable for cable system

No

Adjustability

Rotatable and swiveling

Light source

LED not replaceable

Suitable for number of light sources

1

Version

Without

Material of the housing

Aluminum

Surface protection

powder-coated

Housing color

white

Cover material

Transparent plastic

Brushed surface

No

Voltage type

AC

Nominal voltage

220 – 240 V

Operating device

LED control gear, current-controlled

Without dimming function

No

Reflector

high gloss

Light distributor

Reflector

Light distribution

symmetrical

Beam angle

medium beam 21-40°

Protection class (IP)

IP44

Protection class

II

Max. System performance

8 W

Light color

white

Color temperature

1.800 – 3.000 K

Color rendering index CRI

90-100

Luminous flux

490 lm

Power factor

0,9

Outer diameter

90 mm

Installation height/depth

46 mm

Type of wiring

Suitable for through-wiring

Number of poles

3

Connectable conductor cross-section

0,75 – 2,5 mm²

Connection type

Plug-in terminal

Luminaire luminous efficacy

61 lm/W

Glow wire test according to IEC 60695-2-11

Without

Photobiological safety according to EN 62471

RG1

Color consistency (McAdam ellipse)

SDCM3

Reflector color

silver

Suitable for recessed mounting

Yes

Suitable for ceiling mounting

Yes

With illuminant

Yes

With control gear

Yes

Dimming manufacturer-specific

Yes

Dimming phase cut-off

Yes

Covering the luminaire with thermal insulation material possible

Yes

Country of origin

Norway (NO)

Statistische Warennummer

Lüster und andere elektrische Decken- und Wandleuchten, mit LED-Lichtquelle, aus anderen Stoffen als Kunststoff, keramischen Stoffen oder Glas (94051190)

REACH Indicator

Yes

Datenblatt
AA81219.00.62.pdfdeclaration_rohs_md49-827.pdfdeclaration_roundcentury360_md52-5.pdfarclite_reach_selbstverpflichtungserklaerung_24-07-30_md05-1484.pdfflyer_roundcentury360_362_md41-14.pdfmontageanleitung_rc360_240320_md14-5.pdfausschreibungstext_aa81219_00_62.txt
Suitable for surface mounting

No

Suitable for pendant suspension

No

With motion detector

No

With light sensor

No

Dimming 0-10 V

No

Dimming 1-10 V

No

DALI dimming

No

DMX dimming

No

Dimming DSI

No

Dimming potentiometer (device-integrated)

No

Dimming LineSwitch

No

Dimming Mains voltage modulation

No

Phase control dimming

No

Programmable dimming

No

RF dimming

No

Dimming Sine Wave Reduction

No

Dimming Touch and Dim

No

Dimming Zigbee

No

Dimming with push-button

No

Luminaire with limited surface temperature "D mark" according to EN 60598-2-24

No

Integrated emergency power supply

No

Suitable for VDU workstations according to EN 12464-1

No

Operation via Bluetooth

No
