squareCENTURY 625 BAP - Panels white 32W 85° 3000K CRI80 AC81568.00.91

SKU: 873-AC81568.00.91
Datasheet: Download PDF
For further information, please refer to the data sheet!
High-quality and inexpensive LED flat panel for computer workstations. Suitable for insertion, recessed, surface-mounted and pendant mounting. Suitable for grid ceilings module 625x625. Replacement for T5/T8 recessed luminaire modules. Anti-glare microprism cover UGR < 19. Color tolerance 3 SDCM. Luminous flux decrease after 50,000h L80/B20. Separate control gear with DIP switch current adjustment. High flexibility due to adjustable output currents. 5-year warranty. Net 3900lm
Family

squareCENTURY 625 BAP

Weight

3,24 kg

Product group

Ceiling/wall light (EC002892)

Replaceable operating device

Yes

Dimming DALI-2

No

Luminous flux maintenance with average service life 50,000 h at 25 °C ambient temperature

80 %

Failure rate with average service life of 50,000 h at 25 °C ambient temperature (tq)

10 %

Max. Number of lights Circuit breaker C16

50

Stroboscopic effect value SVM

0,4

Constant luminous flux control

No

Adjustable color temperature

No

Adjustable luminous flux

Steps

Adjustable beam angle

No

Compatible with Apple HomeKit

No

Compatible with Google Assistant

No

Compatible with Amazon Alexa

No

IFTTT support available

No

Housing color

white

Max. System performance

32,00 W

Color temperature

3.000,00 K

Beam angle

Extremely wide beam >80°

Protection class (IP)

IP20

Without dimming function

Yes

Width

620,00 mm

Height/depth

12,50 mm

Length

620 mm

Surface protection housing

powder-coated

Material of the housing

Aluminum

Cover material

Structured plastic

Design of the grid

Without

Voltage type

AC

Nominal voltage

220 – 240 V

Operating device

LED control gear, current-controlled

Light distributor

Diffuser lens/optics/panel

Light distribution

symmetrical

Color consistency (McAdam ellipse)

SDCM3

Color rendering index CRI

80-89

Protection class

I

Glow wire test according to IEC 60695-2-11

Without

Luminaire luminous efficacy

122 lm/W

Light color

white

Light source

LED not replaceable

Power factor

0,95

Type of wiring

Conclusion

Connection type

Plug-in terminal

Photobiological safety according to EN 62471

RG1

Glare limitation (UGR)

19

Suitable for wall mounting

No

Suitable for pendant suspension

Yes

Suitable for ceiling mounting

Yes

Suitable for recessed mounting

Yes

Suitable for surface mounting

Yes

With illuminant

Yes

With control gear

Yes

Suitable for VDU workstations according to EN 12464-1

Yes

Country of origin

China (CN)

Statistische Warennummer

Lüster und andere elektrische Decken- und Wandleuchten, mit LED-Lichtquelle, aus anderen Stoffen als Kunststoff, keramischen Stoffen oder Glas (94051190)

REACH Indicator

Yes
